Part #: 222PIH5

Description: 2" Cast Iron Pump With 5.5 HP Honda® Engine

Standard Lead Times

Specifications

Features & Benefits

"V" Shaped for quicker priming.
6.5 BRIGGS &: Stratton®: INTEKMOTOR
Breather through air cleaner.
Carbon ceramic seal with stainless steel cup and spring with FKM rubber.
Cast iron construction for rugged dependable service.
Cast iron cylinder sleeve.
CAUTION-WARNING: Please do not run pump dry, restrict or reduce port sizes, or dead head pump. This could cause component failure to pump.
DO NOT USE WITH FLAMMABLE LIQUIDS.
Dynamically balanced impeller.
GX Series commercial grade.
Heavy duty flywheel.
Heavy duty slinger seal on motor shaft.
High oil fill
Honda®: ENGINE (below)
Industrial 2-stage air filter.
Large weep holes between pump end and engine.
Legendary reliability/durability.
Oil alert.
OilGuard®: low oil sensor.
Overhead valve.
Powerful Overhead valve (OHV).
PUMP
Pump end separated from engine.
Quiet, easy starting.
Replaceable inlet and outlet flanges.

Kits & Replacements Parts

Item	Description	Part Number	Qty Per
2	Cast Iron Rear Bracket	15703	1
1	Cast Iron Pump Housing Assembly	15712	1
3	Check Valve	12705	1
4	Volute For Cast Iron Pump	15702	1
5	O-Ring (Seal Assembly) EPDM	12710	1
7	O-Ring For Screw Head -EPDM	12717	4
6	5/16-24 X 1¾" HHCS, 18-8 Stainless Steel	12715A	13
8	EPDM Pump Body O-Ring 2-375	12719A	1
9	Impeller Bolt Gasket-FKM	12774VA	1
10	5/16" Flat Washer, 316 Stainless Steel	12901	8
11	3/16 X 3/16 X 5/8 Impeller Key	12902A	1
12	3" Poly Pump Drain/Prime Plug	13777	2
13	EPDM O-Ring ¾" Prime/Drain Plug	13778	2
14	Rear Bracket Shim-15000 Series	15751	1
15	Bracket Motor Mount (Pair)	17033	1
19	5/16"-24 X 1.12" HFS, 316 Stainless Steel	12765A	1
17	5/16" Stainless Steel Lock Washer	V10118	13
18	5/16" Stainless Steel Nut	V10119	4
20	FKM Seal Assembly-Boxed	12713V	1
21	1½" - 2" Pump Handle	15022	1
22	1/2-13 UNC 2B Hex Nut, 18-8SS	17010	1
23	Slinger For 5.5 & 6.5 HP Engine	12716	1
N/S	222 Pump Series Repair Kit-FKM	15000V	1
N/S	222 Pump Series Repair Kit	15999	1
N/S	222 Pump Series Repair Kit	15000	1
N/S	222 Series Pump Repair Kit-FKM	15999V	1
