Part #: 301PBIW
Description: 3" Cast Iron Wet Seal Pump With Bearing Pedestal
Standard Lead Times
Specifications
Family: |
Pumps |
Type: |
Cast Iron |
Style: |
Wet Seal |
Size: |
3" |
Weight |
135.0 lbs |
Features & Benefits
- Double seal contained in ethylene glycol reservoir.
- Durable cast iron construction.
- Dynamically balanced impeller.
- Replaceable inlet and outlet flanges.
- New compact design!
- Pump end separated from engine.
- Replaceable inlet &mdash: outlet flanges.
- Run Dry Capability!
- Warning! Do not use with flammable liquids.
Kits & Replacements Parts
Item |
Description |
Part Number |
Qty Per |
1 |
Cast Iron Pump Housing |
18001 |
1 |
4 |
Check Valve Inlet Gasket |
18013 |
1 |
3 |
Plug For 1 & 1¼" Line Strainer |
12777 |
2 |
2 |
-16 X 1.25" FHSCS, 18-8 Stainless Steel |
18106 |
2 |
7 |
3" Poly Pump Drain/Prime Plug |
13777 |
2 |
6 |
Flange, Inlet 3" National Pipe Thread |
18012 |
1 |
5 |
3" National Pipe Thread Outlet Flange |
18008 |
1 |
11 |
⅜"Stainless Steel Body Nut |
V20019 |
6 |
8 |
Wear Plate |
18004 |
1 |
9 |
Outlet Gasket -EPDM |
18009 |
1 |
12 |
3" Pump Keyed Clamp Assembly |
18129 |
1 |
13 |
3" Wet Seal Assembly Style |
18200A |
1 |
10 |
⅜"Stainless Steel Lock Washer |
V20018 |
18 |
14 |
Adapter Gasket |
18021 |
1 |
15 |
-16 UNC-2A X 1.25 HHCS 304 Stainless Steel |
17704 |
4 |
16 |
5/8-11 Thread Handle |
18033 |
1 |
17 |
5/8-11 Thread Stainless Steel Jam Nut |
18034 |
1 |
18 |
Bearing Pedestal |
18500 |
1 |
21 |
3" Cast Iron Wet Seal Style Impeller |
18206 |
1 |
20 |
3/8-16 x 2 1/8" STUD, 304 SS |
18218 |
6 |
19 |
Cap Screw Hex Head -16 X 1-1/8 Stainless Steel |
18010SS |
8 |
24 |
Wet Seal Mechanical Seal Assembly FKM |
15035 |
1 |
22 |
3" Cast Iron Wet Seal Cover Plate |
18202A |
1 |
26 |
EPDM O-Ring ¾" Prime/Drain Plug |
13778 |
2 |
25 |
3" Cast Iron Wet Seal Style Resevoir/Adapter |
18203A |
1 |
