Part #: 222PBI
Description: 2" Cast Iron Bearing Pedestal With ¾" Straight Keyed Shaft
Non-Standard Lead Times
Specifications
Family: |
Pumps |
Type: |
Cast Iron |
Style: |
Bearing Pedestal |
Size: |
2" |
Weight |
70.0 lbs |
Features & Benefits
- 2" CAST IRON PEDESTAL PUMP
- ¾" straight keyed shaft.
- Carbon ceramic seal with stainless steel cup and spring with FKM rubber.
- Cast iron construction for rugged dependable service.
- Dynamically balanced impeller.
- Easily adaptable to electric motor (flexible coupling not included).
- Replaceable inlet and outlet flanges.
Kits & Replacements Parts
Item |
Description |
Part Number |
Qty Per |
1 |
Cast Iron Pump Housing Assembly |
15712 |
1 |
3 |
Check Valve |
12705 |
1 |
2 |
Cast Iron Rear Bracket |
15703 |
1 |
4 |
Volute For Cast Iron Pump |
15702 |
1 |
5 |
O-Ring (Seal Assembly) EPDM |
12710 |
1 |
6 |
5/16-24 X 1¾" HHCS, 18-8 Stainless Steel |
12715A |
13 |
7 |
O-Ring For Screw Head -EPDM |
12717 |
4 |
8 |
EPDM Pump Body O-Ring 2-375 |
12719A |
1 |
10 |
5/16" Flat Washer, 316 Stainless Steel |
12901 |
4 |
9 |
Impeller Bolt Gasket-FKM |
12774VA |
1 |
11 |
3/16 X 3/16 X 5/8 Impeller Key |
12902A |
1 |
12 |
3" Poly Pump Drain/Prime Plug |
13777 |
2 |
13 |
EPDM O-Ring ¾" Prime/Drain Plug |
13778 |
2 |
14 |
Rear Bracket Shim-15000 Series |
15751 |
1 |
15 |
Cast Iron Impeller |
15772 |
1 |
19 |
1½" - 2" Pump Handle |
15022 |
1 |
16 |
5/16" Stainless Steel Lock Washer |
V10118 |
9 |
17 |
5/16"-24 X 1.12" HFS, 316 Stainless Steel |
12765A |
1 |
18 |
FKM Seal Assembly-Boxed |
12713V |
1 |
21 |
Bearing Pedestal |
12882A |
1 |
20 |
1/2-13 UNC 2B Hex Nut, 18-8SS |
17010 |
1 |
N/S |
222 Pump Series Repair Kit-FKM |
15000V |
1 |
N/S |
222 Series Pump Repair Kit-FKM |
15999V |
1 |
N/S |
222 Pump Series Repair Kit |
15999 |
1 |
N/S |
222 Pump Series Repair Kit |
15000 |
1 |
