Part #: 300PBI
Description: 3" Cast Iron Bearing Pedestal With 1" Straight Shaft
Standard Lead Times
Specifications
Family: |
Pumps |
Type: |
Cast Iron |
Style: |
Bearing Pedestal |
Size: |
3" |
Weight |
125.0 lbs |
Features & Benefits
- Banjo Pumps will not self-prime if — 1750 RPM motor is used.
- IMPORTANT
- Pedestal pump for long coupling to electric motor.
- Pump Only packs complete and ready for attachment to gasoline engine.
- Recommended horsepower, listed below, is for water only. Heavier fluids may require additional horsepower or — trimmed impeller.
Kits & Replacements Parts
Item |
Description |
Part Number |
Qty Per |
1 |
3" National Pipe Thread Outlet Flange |
18008 |
1 |
3 |
Gas Engine Adapter |
18026 |
1 |
2 |
Flange, Inlet 3" National Pipe Thread |
18012 |
1 |
1 |
3" Manifold Cast Iron Pump Outlet Flange |
M18008 |
1 |
2 |
3" Manifold Cast Iron Pump Inlet Flange |
M18012 |
1 |
3 |
3" C Face Adapter |
18048 |
1 |
3 |
Cast Iron Hydraulic Motor Adapter |
18049 |
1 |
4 |
3" Poly Pump Drain/Prime Plug |
13777 |
1 |
7 |
5/8-11 Thread Stainless Steel Jam Nut |
18034 |
1 |
6 |
Plug For 1 & 1¼" Line Strainer |
12777 |
1 |
8 |
Wear Plate |
18004 |
1 |
9 |
Outlet Gasket -EPDM |
18009 |
1 |
11 |
Adapter Gasket |
18021 |
1 |
10 |
Check Valve Inlet Gasket |
18013 |
1 |
12 |
Cap Screw Hex Head -16 X 1-1/8 Stainless Steel |
18010SS |
8 |
14 |
3" Pump Keyed Clamp Assembly |
18129 |
1 |
14 |
Stainless Steel Clamp |
18029 |
1 |
13 |
5/8-11 Thread Handle |
18033 |
1 |
15 |
Cast Iron Pump Housing |
18001 |
1 |
17 |
-16 X 1.25" FHSCS, 18-8 Stainless Steel |
18106 |
2 |
18 |
⅜"Stainless Steel Lock Washer |
V20018 |
8 |
22 |
-16 UNC-2A X 1.25 HHCS 304 Stainless Steel |
17704 |
4 |
20 |
1" Shaft For 3" Pump |
18504 |
1 |
21 |
Bearing Pedestal |
18500 |
1 |
26 |
3/8-16 x 2 1/8" STUD, 304 SS |
18218 |
6 |
23 |
3" Pump Mechanical Seal |
18025 |
1 |
24 |
⅜"Stainless Steel Body Nut |
V20019 |
6 |
23 |
3" Cast Iron Pump Severe Duty Seal |
18025SD |
1 |
27 |
EPDM O-Ring ¾" Prime/Drain Plug |
13778 |
1 |
N/S |
3" Iron Pump Repair Kit |
18100 |
1 |
N/S |
3" Hydraulic Adapter Shaft |
18055 |
1 |
N/S |
Z Rail-Mounting Bracket (Pair) |
18035 |
1 |
N/S |
Bearing |
18502 |
2 |
