Part #: 301POIW

Description: 3" Cast Iron Wet Seal Pump Only

Standard Lead Times

Specifications

Features & Benefits

Kits & Replacements Parts

Item	Description	Part Number	Qty Per
1	Cast Iron Pump Housing	18001	1
2	-16 X 1.25" FHSCS, 18-8 Stainless Steel	18106	2
3	Plug For 1 & 1¼" Line Strainer	12777	2
4	Check Valve Inlet Gasket	18013	1
5	3" National Pipe Thread Outlet Flange	18008	1
6	Flange, Inlet 3" National Pipe Thread	18012	1
7	3" Poly Pump Drain/Prime Plug	13777	2
8	Wear Plate	18004	1
9	Outlet Gasket -EPDM	18009	1
11	⅜"Stainless Steel Body Nut	V20019	6
10	⅜"Stainless Steel Lock Washer	V20018	18
12	3" Pump Keyed Clamp Assembly	18129	1
14	Adapter Gasket	18021	1
13	3" Wet Seal Assembly Style	18200A	1
15	-16 UNC-2A X 1.25 HHCS 304 Stainless Steel	17704	4
16	5/8-11 Thread Handle	18033	1
17	5/8-11 Thread Stainless Steel Jam Nut	18034	1
18	Bearing Pedestal	18500	1
19	Cap Screw Hex Head -16 X 1-1/8 Stainless Steel	18010SS	8
21	3" Cast Iron Wet Seal Style Impeller	18206	1
20	3/8-16 x 2 1/8" STUD, 304 SS	18218	6
22	3" Cast Iron Wet Seal Cover Plate	18202A	1
25	3" Cast Iron Wet Seal Style Resevoir/Adapter	18203A	1
24	Wet Seal Mechanical Seal Assembly FKM	15035	1
26	EPDM O-Ring ¾" Prime/Drain Plug	13778	2
