Part #: M332PIH13W

Description: 3" Cast Iron Manifold Wet Seal Pump With 13 HP Honda® Engine With Electric Start & Pull Rope

Standard Lead Times

Specifications

Features & Benefits

Kits & Replacements Parts

Item	Description	Part Number	Qty Per
2	#13 O-Ring EPDM	12709	4
1	Check Valve	12705	1
4	O-Ring For Screw Head -EPDM	12717	4
5	EPDM Pump Body O-Ring 2-375	12719A	1
6	Plug For 1 & 1¼" Line Strainer	12777	2
8	3/16 X 3/16 X 5/8 Impeller Key	12902A	1
3	5/16-24 X 1¾" HHCS, 18-8 Stainless Steel	12715A	9
9	5/16-24 X 3½" HHCS 316 Stainless Steel	13034	4
7	5/16" Flat Washer, 316 Stainless Steel	12901	8
13	3" Poly Pump Drain/Prime Plug	13777	2
12	-24 X 2¼" HFS	13766	1
10	Adapter Shaft For 3" Poly Wet Seal 11 HP Engine	13055	1
14	EPDM O-Ring ¾" Prime/Drain Plug	13778	2
16	¼" Sq. ¾" Key Stock	16901	1
15	Wet Seal Mechanical Seal Assembly EPDM	15035E	1
18	5/8-11 Thread Handle	18033	1
19	5/8-11 Thread Stainless Steel Jam Nut	18034	1
23	3" Cast Iron Wet Seal Pump Volute	19702	1
22	3" Cast Iron Wet Seal Pump Reservoir	19201W	1
25	3" Pump Impeller 316 Stainless Steel	19772SS	1
26	#204 O-Ring EPDM	A204	1
24	3" Cast Iron Wet Seal Rear Bracket	19703W	1
29	5/16" Stainless Steel Lock Washer	V10118	13
27	3" Cast Iron Manifold Pump Body	M19712X	1
30	5/16" Stainless Steel Nut	V10119	4
