Part #: M332POIW
Description: 3" Cast Iron Manifold Wet Seal Pump Only
Non-Standard Lead Times
Specifications
Family: |
Pumps |
Type: |
Cast Iron |
Style: |
Wet Seal |
Size: |
3" |
Weight |
70.532 lbs |
Features & Benefits
- Carbon ceramic seal with stainless steel cup and spring with :EPDM rubber.
- Durable cast iron construction.
- Dynamically balanced impeller.
- Pump end separated from engine.
- V Shaped for quicker priming.
- Run Dry Capability!
- Due to weight and size of pump, Banjo ships this by truck only.
- Engine warranty service available at authorized dealers.
- WARNING! DO NOT USE WITH FLAMMABLE LIQUIDS.
Kits & Replacements Parts
Item |
Description |
Part Number |
Qty Per |
1 |
Check Valve |
12705 |
1 |
2 |
#13 O-Ring EPDM |
12709 |
4 |
3 |
5/16-24 X 1¾" HHCS, 18-8 Stainless Steel |
12715A |
9 |
4 |
O-Ring For Screw Head -EPDM |
12717 |
4 |
5 |
EPDM Pump Body O-Ring 2-375 |
12719A |
1 |
7 |
5/16" Flat Washer, 316 Stainless Steel |
12901 |
8 |
6 |
Plug For 1 & 1¼" Line Strainer |
12777 |
2 |
8 |
3/16 X 3/16 X 5/8 Impeller Key |
12902A |
1 |
9 |
5/16-24 X 3½" HHCS 316 Stainless Steel |
13034 |
4 |
10 |
Adapter Shaft For 3" Poly Wet Seal 11 HP Engine |
13055 |
1 |
13 |
3" Poly Pump Drain/Prime Plug |
13777 |
2 |
12 |
-24 X 2¼" HFS |
13766 |
1 |
14 |
EPDM O-Ring ¾" Prime/Drain Plug |
13778 |
2 |
16 |
¼" Sq. ¾" Key Stock |
16901 |
1 |
18 |
5/8-11 Thread Handle |
18033 |
1 |
15 |
Wet Seal Mechanical Seal Assembly EPDM |
15035E |
1 |
19 |
5/8-11 Thread Stainless Steel Jam Nut |
18034 |
1 |
22 |
3" Cast Iron Wet Seal Pump Reservoir |
19201W |
1 |
23 |
3" Cast Iron Wet Seal Pump Volute |
19702 |
1 |
24 |
3" Cast Iron Wet Seal Rear Bracket |
19703W |
1 |
25 |
3" Pump Impeller 316 Stainless Steel |
19772SS |
1 |
26 |
#204 O-Ring EPDM |
A204 |
1 |
27 |
3" Cast Iron Manifold Pump Body |
M19712X |
1 |
30 |
5/16" Stainless Steel Lock Washer |
V10118 |
13 |
31 |
5/16" Stainless Steel Nut |
V10119 |
4 |
